Tractor Mobile Trench Digger

The Tractor Mobile Trench Digger is used while ground digging in agriculture and construction industry. The digger can cut narrow as well as deep trenches without any challenge and the users can customize the angle of the boom in order to control the depth of the cut. These diggers are available with heavy-duty frame and structural framework that possess superior strength and stability. The hydraulic cylinders are used in the digger that can work under different conditions. The digger is available with various options in adjusting the depth so it could go far deeper if required.

FEATURES

• Heavy Duty frame & Structural framework brings in greater strength & stability.
• Reliable & heavy duty hydraulic cylinder that works under varying work conditions.
• Easy Depth adjustment.
• Can cut narrow and deep trenches.
• The angle of the boom can be adjusted to control the depth of the cut.
• To cut a trench, the boom is held at a fixed angle while the machine creeps slowly.

TECHNICAL SPECIFICATIONS

Model	FK-TTD
Body Frame	150 x 150 mm & 175 x 175 mm Square Box
Lenght	1875 mm
Width	1475 mm
Height	1200 mm
Working Width	200 mm / 225 mm (Optional)
Chain Width	50 mm
No. Hydraulic Jack	02 (Two Way)
Type Of Bearings	Tapper Roller
No. Of Gear Box	2
Require Power Hp	65 HP & Above With Gear Option 150 m/hr
Approx. Weight	800 Kgs.

NOTE : The contents of this catalogue are only giving information to the end user without engagement from our side. The company can modify SPECIFICATIONS of the total machine and it's components without any previous notice.
